Drone 30x Zoom Gimbal Q30F

3306.60 $

Out of stock



Professional 3-axis High-precise FOC Program in Gimbal Q30F

There is no doubt that the Gimbal Q30F is a highly optimized 3-axis camera gimbal drone with the pinpoint accuracy of motor rotation, a control accuracy of *0.02°, and a dedicated processor. In order to ensure a more stable data transmission and greater durability, the Q30F features a unique mechanically limited design and hidden wires. By using four damping balls and a lightweight damping board, vibrations can be eliminated from the video, creating a smooth, seamless video. Despite the fact that gimbal rotation continues to be possible, 300° rotation is still possible.

30x Optical Zoom Camera

Even at high speeds, it is possible to capture stable, smooth footage images. It is designed for UAV aerial photography and has 4 Mega effective pixels, a 30x optical autofocus setting, HD 1080p video, a fast autofocus speed, as well as a small size.


q30f - Gimbal Q30F - MotioNew - 4

Multi Output Methods Optional in Gimbal Q30F

The Q30F support HDMI and AV output. HDMI is 1080P and AV output is 720p.

q30f2 - Gimbal Q30F - MotioNew - 5

Multi Control Methods of Gimbal Q30F

Default PWM and Serial port TTL control. SBUS is optional. With Viewpro software Viewlink you can fulfill TTL control.

q30f3 - Gimbal Q30F - MotioNew - 6

Control box signal interfaces:

q30f4 - Gimbal Q30F - MotioNew - 7


This 30x zoom gimbal Q30F has been widely used in various fields like public security, electric power, fire, zoom aerial photography and other industries in the application of drones.

q30f5 - Gimbal Q30F - MotioNew - 8

Compatible with Viewport

This payload camera Q30F is compatible with Viewpro quick release connector Viewport. Viewport is an option known as easy assembly, plug and play.

q30f5I - Gimbal Q30F - MotioNew - 9
For a comprehensive reading of related products, please visit the Motionew website.

Additional information

Weight 0.670 kg
Dimensions 13 × 15 × 16 cm


Hardware Parameter
Working voltage 12V ~ 16V
Input voltage 3S ~ 6S
Output voltage 5V (connect with PWM)
Dynamic current 450mA @ 12V
Idle current 330mA @ 12V
Power consumption ≤5.4W
Working environment temp. -20℃ ~ +60℃
Output micro HDMI (HD output 1080P 60fps) / Analog
Local-storage SD card (Up to 32G, class 10, FAT32 or ex FAT format)
Control method PWM /S.bus/TTL


Gimbal Spec
Angle range of structure design Pitch/Tilt: -50°~110°, Roll: ±70°, Yaw/Pan: ±300°
Angle range of software design Pitch/Tilt: -40°~90°, Yaw/Pan: ±290°
Vibration angle Pitch/Roll: ±0.02°, Yaw:±0.02°
One-key to center


Camera spec
Imager Sensor 1/3inch CMOS
Total pixel 4MP
Effective pixel 2688*1520
Dynamic range 65dB
Lens 5MP
Optical zoom 30x, F=4.5~135mm
Min object distance 1.5M
Viewing angle Horizontal: 59.8°(Wide end) ~ 2.77°(Tele end)
Vertical: 40.5°(wide end) ~ 1.48°(tele end)
Focus: 66.6°(wide end) ~ 7.2°(tele end)
Sync system Progressive scanning
Local video 1080P 30fps local TF card
HD output 1080P/720/480P 60fps HDMI1.4
AV output Standard CVBS 1Vp-p
S/N ratio 38dB
Min illumination Color [email protected]
Backlight compensation Backlight compensation/strong light inhibition
Gain Auto
White balance Auto/Manual
Shutter speed Auto
Control system UART/IR/PWM
Communication protocol PELCO-D, Hitachi protocol or VISCA
Focus Auto/Manual/One-time automatic focus
Focus speed 2s
Lens initialization Built-in
User presetting bit 20 sets
Image rotation 180°, Horizontal/Vertical mirror image
OSD Not support
photo format JPEG
Video format MP4


Packing Information
N.W. 670g
Product meas. 121*147*154.8mm

Product contents

Product contents
