Semi Solid-State Battery | Model Ultra Rock Ultra HV battery 12s 17000mAh330Wh/kg Energy Density 25C discharge Rate
420.00 $
Payment Methods:
Please inform us about the connector type that best meets your needs.
We offer a wide range of batteries in various sizes and models, though some are not yet publicly listed. Please feel free to send us a message if your required model is not listed.
** All certificates and reports required for shipping and customs clearance including MSDS, UN38.3, RoHS, and DGM are available. **
General Specifications
Ultra HV battery 12S 17000mAh Ultra HV semi solid-state battery is only 2.4kg, with 330Wh/kg pack energy density, and Standard Current discharge rate is 5C, Continuous current discharge rate is 15C and Peak current discharge rate is 25C.
The Ultra Rock Ultra HV Semi Solid-State battery is a Semi Solid-state Li-ion battery series that has a higher discharge current and higher cell voltage compared to a normal solid-state Li-ion battery. The discharge interval of each battery cell is from 2.7v to 4.45v and the discharge rate can be up to 25C.
Advantages of battery 12s 17000mAh
Compared to traditional semi solid-state li-ion batteries, the Ultra HV Solid-state Li-ion battery has a lightweight and higher energy density. The drone endurance time will be increased by using this model of batteries. In contrast to normal Li-ion batteries, solid-state batteries do not heat during usage even when a high current is being drawn from the battery. They are more resilient to shocks and hits.
Battery 12s 17000mAh applications
Ultra HV Solid-state Li-ion battery is suitable for most UAVs or other electrical equipment that requires a long endurance time: Agriculture drones, Industrial multi-copters, VTOLs, Robots, Surface ships, etc.
Notice: Please do not assemble the battery privately,Parallel charging for two packs of batteries maybe lead to short circuit or ignition.If no otherwise specified, an interval rest time is 30min between charging and discharging.
For a comprehensive reading of related products, please visit the Motionew website.
FAQ – Ultra Rock Semi Solid-State 12S 17,000mAh Battery
1. What is this battery used for?
This semi solid-state HV battery is designed for UAVs, VTOL drones, and industrial robotics requiring high-voltage stability, long endurance, and safe operation under high discharge rates.
2. What are the main technical specifications?
-
Voltage: 12S (2.7–4.45V per cell)
-
Capacity: 17,000mAh
-
Energy Density: 330 Wh/kg
-
Weight: 2.4 kg
-
Discharge Rate: 5C standard, 15C continuous, 25C peak
-
Chemistry: Ultra HV semi solid-state Li-ion
This design ensures lightweight integration, high-current delivery, and greater endurance compared to conventional Li-ion batteries.
3. Which systems are compatible with this battery?
It is suitable for large UAVs, VTOL platforms, long-range drones, and robotics using 12S HV packs. Connector types can be specified depending on integration needs.
4. Is OEM or bulk purchasing available?
Yes. Motionew provides OEM supply, bulk order options, and logistics solutions for UAV manufacturers, enterprise operators, and research institutions.
5. What documentation and certifications are provided?
Each battery comes with MSDS, UN38.3, RoHS, and DGM certificates for international shipping and customs clearance. Technical support and integration guidance are also available.
6. What are the B2B payment and invoicing options?
Motionew supports international wire transfers, issues official commercial invoices, and offers flexible payment terms for approved enterprise customers.
Specifications
Voltage | Nominal: 47.4V, Full: 53.4v |
Cell Voltage | 4.45v/cell |
Capacity | 17000mAh |
Standard Discharge Rate | 5C |
Continuous Discharge Rate | 15C |
Max.Discharge | 25C |
Energy | 330Wh/kg |
Size | 235*92*75mm |
Weight | 2425 |
Product contents
1x Ultra Rock Solid-state Battery 12s 17000mAh
Documents
All certificates and reports required for shipping and customs clearance including MSDS, UN38.3, RoHS, and DGM are available.
Please contact us for more information.
You must be logged in to post a review.
Battery cells |
12S |
---|---|
Battery Dimensions |
235*92*75mm |
Battery Continuous C rate |
15C |
Battery Energy Density |
330Wh/kg |
Battery Max Peak C rate |
25C |
Battery Type |
ULiHV |
Battery Weight |
2425 |
Battery Nominal Voltage |
3.95 |
Battery Full Voltage |
4.45v |
Battery Capacity |
17000mAh |
