Gimbal Camera QIR25250T | 10x Optical Zoom Cooled MWIR IR Thermal 50Hz | 8mm Prime lens EO Sensor
Payment Methods:
Description
QIR25250T – 10x Optical Zoom MWIR Dual Sensor Tracking Gimbal for UAVs
The QIR25250T is a high-performance dual-sensor gimbal camera, combining long-range 10x optical zoom cooled MWIR thermal imaging with a 1080p EO sensor with 8mm prime lens for precise aerial observation and object tracking. Designed for UAV platforms requiring mission-critical performance in ISR (Intelligence, Surveillance, and Reconnaissance), security, and industrial inspection, this payload delivers real-time situational awareness in all lighting conditions.
Key Features:
-
Dual Sensor System: 1/2.3″ CMOS EO camera + 640×512 cooled MWIR thermal imager
-
10x Optical Zoom: 25–250mm thermal zoom lens for long-range detection
-
Intelligent Tracking: Built-in target tracking for dynamic object following
-
Multi-Protocol Control: Compatible with PWM, S.BUS, UART, TCP/UDP
-
Full HD Output: 1080p video via Micro HDMI or IP stream
-
Local Storage: Supports SD cards up to 512GB
-
UAV-Ready Design: Compact, vibration-resistant housing with 4S–6S voltage input
Specifications Table
| Component | Specification |
|---|---|
| EO Sensor | 1/2.3 inch CMOS, 1920×1080 @ 30fps |
| EO Lens | 8mm fixed focus, FOV 45°×30° |
| Thermal Resolution | 640×512, 15μm pixel pitch |
| Thermal Zoom | 25–250mm, 10x optical zoom |
| Target Tracking | Supported |
| Video Output | 1080p via Micro HDMI / IP stream |
| Control Protocols | PWM, S.BUS, UART, TCP, UDP |
| Local Storage | Up to 512GB |
| Operating Voltage | 4S to 6S (LiPo input) |
| Weight | 2.5 kg |
| Dimensions (mm) | 165 × 188.2 × 238.4 |
Built for aerial surveillance, night-time reconnaissance, and long-range target tracking, the QIR25250T offers unmatched precision in a compact, UAV-friendly package.
Explore more professional gimbal camera payloads on Motionew to enhance your UAV mission capabilities.
For a comprehensive reading of related products, please visit the Motionew website.
Simple FAQ (QIR25250T – Engineers & B2B Buyers)
1. What is the QIR25250T Gimbal used for?
The QIR25250T is a cooled MWIR thermal gimbal camera designed for high-precision UAV missions such as border security, industrial inspection, search and rescue, and long-range thermal surveillance—even in total darkness or extreme conditions.
2. What are the key technical features of the QIR25250T?
It features a cooled MWIR sensor with a 25–250mm continuous optical zoom lens (10x), providing exceptional long-range infrared detection. The gimbal also includes 3-axis stabilization, temperature measurement, object tracking, and IP video output with low-latency performance.
3. Which UAVs are compatible with this gimbal?
The QIR25250T supports PWM, S.BUS, and serial control protocols, making it compatible with heavy multirotors, fixed-wing UAVs, and VTOL platforms used in tactical or industrial-grade operations.
Business & Operational FAQs
4. Is the QIR25250T available for OEM or bulk purchase?
Yes. Motionew offers OEM supply, volume pricing, and technical integration assistance for enterprise drone manufacturers and defense-related applications.
5. What documentation and support are included?
Each unit ships with a detailed wiring diagram, user guide, and access to remote technical support to ensure seamless integration into complex UAV platforms.
6. What payment and invoicing options are available for business clients?
Motionew supports international wire transfers, provides official business invoicing, and offers flexible payment terms for qualified B2B customer
Specifications
Specifications
| Parameter Table | |
| Image Sensor | 1/2.3 inch CMOS Sensor |
| Fixed focal length lens | 8mm fixed focus, FOV 45°*30° |
| Resolution and frame rate | 1920*1080 |
| Thermal Imager | 640*512, 25~250mm focal length, 10x optical zoom , 15μm |
| Target Tracking | √ |
| Operating voltage | 4S~6S |
| Output method | 1080p micro HDMI/IP |
| Control method | PWM/S.BUS/UART/TCP/UDP |
| Local Storage | Maximum support 512G |
| net weight | 2.5 kg |
| Product size | 165*188.2*238.4mm |
Product contents
Product contents
Please contact us for more information.
Documents
Documents
click here to download QIR25250T.Manual
Reviews
You must be logged in to post a review.
| Gimbal Control Method |
Ethernet ,PWM ,SBUS ,UART |
|---|---|
| Number of Sensors |
2 Sensors |
| EO Sensor resolution |
1920×1080 |
| Thermal Sensor Lens |
10x optical |
| Thermal Sensor resolution |
640×512 |
| AI Object Tracking |
Yes |
| Gimbal Video Output |
Ethernet ,SDI |
| Gimbal Weight |
2429g |
| Gimbal Dimensions |
165×188.2×238.4mm |
| EO Sensor Lens |
8mm |
