Semi Solid-State Battery | Model Ultra Rock Ultra HV battery 3s 2800mAh 330Wh/kg Energy Density 25C discharge Rate

23.00 $

Payment Methods:

Payment methods - ultra hv battery 3s 2800mah 330wh/kg energy density 25c discharge rate - motionew - 2
Description

Please inform us about the connector type that best meets your needs.
We offer a wide range of batteries in various sizes and models, though some are not yet publicly listed. Please feel free to send us a message if your required model is not listed.

** All certificates and reports required for shipping and customs clearance including MSDS, UN38.3, RoHS, and DGM are available. **


General Specifications

Ultra HV battery 3S 2800mAh Ultra HV semi solid-state battery is only 0.1kg, with 330Wh/kg pack energy density, and Standard Current discharge rate is 5C, Continuous current discharge rate is 15C and Peak current discharge rate is 25C.

The Ultra Rock Ultra HV Semi Solid-State battery is a Semi Solid-state Li-ion battery series that has a higher discharge current and higher cell voltage compared to a normal solid-state Li-ion battery. The discharge interval of each battery cell is from 2.7v to 4.45v and the discharge rate can be up to 25C.

Advantages of battery 3s 2800mAh

Compared to traditional semi solid-state Li-ion batteries, the Ultra HV Solid-state Li-ion battery has a lightweight and higher energy density. The drone endurance time will be increased by using this model of batteries. In contrast to normal Li-ion batteries, solid-state batteries do not heat during usage even when a high current is being drawn from the battery. They are more resilient to shocks and hits.

Battery 3s 2800mAh applications

Ultra HV Solid-state Li-ion battery is suitable for most UAVs or other electrical equipment that requires a long endurance time: Agriculture drones, Industrial multi-copters, VTOLs, Robots, Surface ships, etc.

Semi solid-state battery | model ultra rock ultra hv battery 3s 2800mah 330wh/kg energy density 25c discharge rate Specifications of semi solid-state battery | model ultra rock ultra hv battery 3s 2800mah 330wh/kg energy density 25c discharge rate Main features of semi solid-state battery | model ultra rock ultra hv battery 3s 2800mah 330wh/kg energy density 25c discharge rate

For a comprehensive reading of related products, please visit the Motionew website.

FAQ – Ultra Rock Semi Solid-State 3S 2800mAh Battery

1. What is this battery used for?
This compact semi solid-state HV battery is designed for small UAVs, FPV drones, and electronic systems requiring lightweight power with high energy density and reliable discharge performance.

2. What are the main technical specifications?

  • Voltage: 3S (2.7–4.45V per cell)

  • Capacity: 2800mAh

  • Energy Density: 330 Wh/kg

  • Weight: 0.1 kg

  • Discharge Rate: 5C standard, 15C continuous, 25C peak

  • Chemistry: Semi solid-state Li-ion (Ultra HV type)
    It ensures lightweight integration, stable thermal behavior, and safe high-current output.

3. Which systems are compatible with this battery?
It is suitable for micro-to-small UAVs, FPV racing drones, and portable electronic systems that operate on 3S high-voltage packs. Connector type can be specified based on integration needs.

4. Is OEM or bulk purchasing available?
Yes. Motionew supports OEM branding, bulk orders, and custom logistics for drone makers, FPV kit providers, and research institutions.

5. What documentation and certifications are provided?
Each battery is shipped with MSDS, UN38.3, RoHS, and DGM certificates to comply with global transport and customs requirements. Handling and integration guidelines are also included.

6. What are the payment and invoicing options for B2B clients?
Motionew accepts international wire transfers, issues official commercial invoices, and offers flexible payment terms for approved enterprise buyers.

Specifications

Specifications

Voltage Nominal: 11.8V, Full: 13.35V
Cell Voltage 4.45v/cell
Capacity 2800mAh
Standard Discharge Rate 5C
Continuous Discharge Rate 15C
Max./Peak Discharge Rate 25C
Energy 330Wh/kg
Size 73*39*24mm
Weight 100g



Product contents

Product contents

1x Ultra High Voltage Solid-state Battery 3s 2800mAh

Documents

Documents

All certificates and reports required for shipping and customs clearance including MSDS, UN38.3, RoHS, and DGM are available.

Please contact us for more information.



Reviews
0 reviews
0
0
0
0
0

There are no reviews yet.

Be the first to review “Semi Solid-State Battery | Model Ultra Rock Ultra HV battery 3s 2800mAh 330Wh/kg Energy Density 25C discharge Rate”

Specification:

Battery cells

3S

Battery Dimensions

73*39*24mm

Battery Continuous C rate

15C

Battery Energy Density

330Wh/kg

Battery Max Peak C rate

25C

Battery Type

ULiHV

Battery Weight

100

Battery Nominal Voltage

3.95

Battery Full Voltage

4.45v

Battery Capacity

2800mAh
