ZeroOne OneGNSS M9N GPS Module ublox M9N Four Star Co Reception

The ZeroOne OneGNSS M9N GPS Module is a professional grade navigation solution developed for UAV platforms that require stable positioning, fast convergence, and robust sensor fusion. Built around the ublox M9N GNSS chipset, this module supports four star co reception, allowing simultaneous tracking of multiple satellite constellations to significantly improve positioning accuracy and reliability in complex flight environments.

For UAV engineers and system integrators, reliable GNSS data is essential not only for navigation but also for flight safety, mission efficiency, and autonomous operation. This GPS module is designed to meet those expectations by integrating positioning, heading, altitude sensing, and safety signaling into a compact and highly compatible unit.

As part of the broader GPS Module ecosystem, this solution is well suited for multirotor, VTOL, and fixed wing UAVs that rely on precise GNSS data for stable flight control and autonomous missions.

Multi constellation GNSS with ublox M9N chipset

At the core of the ZeroOne OneGNSS M9N GPS Module is the ublox M9N GNSS engine, which supports four star co reception across major global navigation satellite systems. By receiving signals from multiple constellations simultaneously, the module delivers faster time to first fix, improved positioning stability, and higher resistance to signal obstruction or interference.

This capability is particularly valuable in urban environments, mountainous regions, and long range missions where satellite visibility can vary rapidly. The M9N architecture ensures consistent performance even when UAVs operate in challenging RF conditions.

The module outputs high quality GNSS data suitable for advanced navigation algorithms, making it a strong companion for modern Flight controller platforms used in professional UAV systems.

Industrial grade compass for accurate heading control

Accurate heading information is critical for precise navigation, waypoint tracking, and yaw stability. The integrated RM3100 industrial grade compass provides high resolution magnetic field sensing with excellent noise immunity. Compared to consumer level magnetometers, the RM3100 offers superior consistency and reduced sensitivity to electromagnetic interference generated by onboard power systems and payloads.

This makes the ZeroOne OneGNSS M9N GPS Module especially suitable for UAVs carrying high current propulsion systems, gimbals, or communication payloads. When properly calibrated and mounted, the compass data integrates seamlessly with the flight controller to deliver stable heading estimation throughout the mission.

High precision altitude data with ICP20100 barometer

Altitude accuracy plays a major role in flight stability, terrain following, and automated landing procedures. This GPS module integrates the ICP20100 high precision barometer, delivering reliable pressure based altitude measurements that complement GNSS altitude data.

By combining barometric and GNSS inputs, flight controllers can achieve smoother altitude hold and improved vertical control, particularly during low altitude operations or in GNSS degraded environments. This sensor combination supports advanced flight modes and enhances overall system redundancy.

Integrated safety switch and buzzer for operational reliability

To simplify installation and enhance operational safety, the ZeroOne OneGNSS M9N GPS Module includes an integrated safety switch and buzzer. These components provide clear system status feedback during power up, arming, and pre flight checks.

For professional UAV operators and maintenance teams, built in audible and tactile indicators reduce setup time and minimize the risk of improper arming or configuration errors. This integration also reduces wiring complexity, contributing to a cleaner and more reliable airframe installation.

DroneCAN protocol for modern UAV integration

The module supports DroneCAN protocol, enabling robust digital communication with compatible flight controllers and onboard systems. DroneCAN offers improved noise immunity, flexible network architecture, and standardized messaging compared to traditional serial interfaces.

This makes the ZeroOne OneGNSS M9N GPS Module well suited for scalable UAV architectures, including complex systems such as vtol drone platforms and advanced multirotor configurations. MotioNew engineers regularly support customers in configuring DroneCAN networks to ensure stable data flow and optimal system performance.

Integration insights from MotioNew engineers

MotioNew provides more than just hardware supply. Our engineering team supports customers with integration guidance, compatibility validation, and system level optimization. When deploying the OneGNSS M9N GPS Module, MotioNew engineers can assist with mounting recommendations, electromagnetic interference mitigation, and parameter tuning for popular flight controller ecosystems.

This technical support ensures that customers achieve the full performance potential of the ublox M9N GNSS engine, RM3100 compass, and ICP20100 barometer in real world UAV applications.

Suitable UAV applications and system compatibility

The ZeroOne OneGNSS M9N GPS Module is suitable for a wide range of professional UAV applications, including aerial mapping, inspection, surveillance, and autonomous flight research. It integrates well with modern flight control systems used in Multirotor Drone platforms as well as fixed wing and VTOL UAVs.

Its combination of multi constellation GNSS, industrial grade sensors, and DroneCAN communication makes it a flexible choice for both new designs and system upgrades.

Discover more GPS Options

FAQs

Is the ZeroOne OneGNSS M9N GPS Module suitable for professional UAV navigation systems?

Yes. The combination of ublox M9N four star co reception, RM3100 industrial grade compass, and ICP20100 barometer makes this GPS module suitable for professional UAV navigation systems that require stable positioning, accurate heading, and reliable altitude data. MotioNew supports system integration and validation for professional deployments.

Does MotioNew support bulk or wholesale procurement for this GPS module?

MotioNew offers competitive pricing for bulk and wholesale orders of the ZeroOne OneGNSS M9N GPS Module. Our team supports procurement planning, batch consistency verification, and long term supply for OEMs and enterprise UAV projects.

Can MotioNew assist with DroneCAN configuration and integration?

Yes. MotioNew engineers provide technical support for DroneCAN configuration, setup, and flight controller integration. This ensures reliable communication and optimal performance in complex UAV systems.

What lead time and support options are available for B2B buyers?

MotioNew works closely with manufacturers and logistics partners to support stable lead times for B2B buyers. We also provide pre sales technical consultation, integration guidance, and after sales support for bulk and wholesale customers.
